BGW 350-480A (800/60), 200kW, 1480 centrifugal horizontal pump

BGW 350-480A (800/60), 200kW, 1480 centrifugal horizontal pump

Click image for a larger view

Code: 1026630

(0 review)

Producer	BTS Engineering
Material	cast iron
PumpType	console
Output pipe diameter	DN350
Input pipe diameter	DN350
Material of flow channel	cast iron
Max.temperature, C	120
Explosion protection	No
Pump capacity, m3/h	800
Serial number of the pump	BGW
Drive Type	electric
Feed height, m	60
Country of Origin	China
Warranty, months	12
Power capacity, kW	200
Power supply	3х380 V, 50 Hz
Rate of turn, rpm	1 480
Protection	IP55
Seal	Mechanical Seal, Carbon-SiC-NBR
Type of configuration	with engine
Installation Type	horizontal
Nom.flow rate, m3/h	800
Nom.head, m	60

Show all features (23)

Documentation

Description BGW 350-480A (800/60), 200kW, 1480 centrifugal horizontal pump

BGW series pumps are used for: - fire extinguishing systems; - municipal water supply; - technical water supply systems; - air conditioning and heating systems; - liquid cooling systems; - washing, filtration and cleaning systems; - use in swimming pools; - fountain installations; - watering and irrigation of fields.

Category: Monobloc Console Pumps Made Of Cast Iron

Features BGW 350-480A (800/60), 200kW, 1480 centrifugal horizontal pump

Producer	BTS Engineering
Material	cast iron
PumpType	console
Output pipe diameter	DN350
Input pipe diameter	DN350
Material of flow channel	cast iron
Max.temperature, C	120
Explosion protection	No
Pump capacity, m3/h	800
Serial number of the pump	BGW
Drive Type	electric
Feed height, m	60
Country of Origin	China
Warranty, months	12
Power capacity, kW	200
Power supply	3х380 V, 50 Hz
Rate of turn, rpm	1 480
Protection	IP55
Seal	Mechanical Seal, Carbon-SiC-NBR
Type of configuration	with engine
Installation Type	horizontal
Nom.flow rate, m3/h	800
Nom.head, m	60
