| Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| PumpType | console |
| Output pipe diameter | DN65 |
| Input pipe diameter | DN80 |
| Max.temperature, C | 120 |
| Weight, kg | 127 |
| Explosion protection | No |
| Pump capacity, m3/h | 114 |
| Serial number of the pump | BZ |
| Drive Type | electric |
| Feed height, m | 43 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 18,5 |
| Length of transport packing, cm | 75 |
| Width of transport packing, cm | 52 |
| Height of transport packing, cm | 37 |
| Power supply | 3х380 V, 50 Hz |
| Protection | IP55 |
| Housing material | AISI 304 stainless steel |
| Seal | Mechanical Seal, Carbon-SiC-NBR |
| Type of configuration | with engine |
| Installation Type | horizontal |
| Nom.flow rate, m3/h | 114 |
| Nom.head, m | 43 |
| Impeller material | AISI 304 stainless steel |
| Transport packing volume, cbm | 0,144 |
| Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| PumpType | console |
| Output pipe diameter | DN65 |
| Input pipe diameter | DN80 |
| Max.temperature, C | 120 |
| Weight, kg | 127 |
| Explosion protection | No |
| Pump capacity, m3/h | 114 |
| Serial number of the pump | BZ |
| Drive Type | electric |
| Feed height, m | 43 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 18,5 |
| Length of transport packing, cm | 75 |
| Width of transport packing, cm | 52 |
| Height of transport packing, cm | 37 |
| Power supply | 3х380 V, 50 Hz |
| Protection | IP55 |
| Housing material | AISI 304 stainless steel |
| Seal | Mechanical Seal, Carbon-SiC-NBR |
| Type of configuration | with engine |
| Installation Type | horizontal |
| Nom.flow rate, m3/h | 114 |
| Nom.head, m | 43 |
| Impeller material | AISI 304 stainless steel |
| Transport packing volume, cbm | 0,144 |
Download instructions, catalog for BZ 65-200/18.5 centrifugal monoblock pump for mash made of stainless steel
