BZm 32-160/1.5 centrifugal monoblock pump for mash

BZm 32-160/1.5 centrifugal monoblock pump for mash

Click image for a larger view

More +4

Code: 1019153

(0 review)

Producer	BTS Engineering
Material	AISI 304 stainless steel
PumpType	console
Output pipe diameter	32
Input pipe diameter	50
Max.temperature, C	120
Weight, kg	22,5
Explosion protection	No
Pump capacity, m3/h	12
Serial number of the pump	BZm
Drive Type	electric
Feed height, m	24.5
Country of Origin	China
Warranty, months	12
Power capacity, kW	1,5
Length of transport packing, cm	43
Width of transport packing, cm	34
Height of transport packing, cm	27
Power supply	1х220 V, 50 Hz
Protection	IP55
Housing material	AISI 304 stainless steel
Seal	Mechanical Seal, Carbon-SiC-NBR
Type of configuration	with engine
Installation Type	horizontal
Nom.flow rate, m3/h	12
Nom.head, m	24.5
Impeller material	AISI 304 stainless steel
Transport packing volume, cbm	0,039
Application	браги, мочевины, жидких удобрений, КАС, соков, аммиачной смеси, селевого раствора, salt, сыроватки, каустика, сушильной камеры, молока, food, brew, wine, wort, CIP-washing, полива, градирни, ледяной воды, оборотного водоснабжения, отопления, сушки, повышения давления, water

Show all features (29)

Documentation

Description BZm 32-160/1.5 centrifugal monoblock pump for mash

Monoblock pump BZ made of stainless steel. Purpose: water supply, pressure boosting, pumping of liquid mineral fertilizers, KAS, in agriculture, food industry, pumping of wort, yeast, mash, milk, beer, kvass, enzymes, juices, wine, fermented milk products, salt solutions, oil, vegetable oil with a temperature of up to 120C. Analog pump Ebara 3M, Pedrollo F-INOX, Speroni CNX, Calpeda MXH, Lowara CA. The pump is used to work with both non-aggressive and aggressive liquids that are chemically compatible with the materials of the pump part.

Category: Monobloc Stainless Console Pumps

Features BZm 32-160/1.5 centrifugal monoblock pump for mash

Producer	BTS Engineering
Material	AISI 304 stainless steel
PumpType	console
Output pipe diameter	32
Input pipe diameter	50
Max.temperature, C	120
Weight, kg	22,5
Explosion protection	No
Pump capacity, m3/h	12
Serial number of the pump	BZm
Drive Type	electric
Feed height, m	24.5
Country of Origin	China
Warranty, months	12
Power capacity, kW	1,5
Length of transport packing, cm	43
Width of transport packing, cm	34
Height of transport packing, cm	27
Power supply	1х220 V, 50 Hz
Protection	IP55
Housing material	AISI 304 stainless steel
Seal	Mechanical Seal, Carbon-SiC-NBR
Type of configuration	with engine
Installation Type	horizontal
Nom.flow rate, m3/h	12
Nom.head, m	24.5
Impeller material	AISI 304 stainless steel
Transport packing volume, cbm	0,039
Application	браги, мочевины, жидких удобрений, КАС, соков, аммиачной смеси, селевого раствора, salt, сыроватки, каустика, сушильной камеры, молока, food, brew, wine, wort, CIP-washing, полива, градирни, ледяной воды, оборотного водоснабжения, отопления, сушки, повышения давления, water
