TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump
Click image for a larger view
TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump
TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump
TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump
TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump
TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump

TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump

Code: 1049116
(0 review)
ProducerBTS Engineering
MaterialAISI 304 stainless steel
PumpTypeconsole
Output pipe diameterDN25
Input pipe diameterDN25
Material of flow channelAISI 304 stainless steel
Weight, kg39
Explosion protectionYes
Suction capacity (NPSH), m2,3
Pump capacity, m3/h4
Serial number of the pumpTKHWB
Drive Typeelectric
Feed height, m32
Country of OriginChina
Warranty, months12
Power capacity, kW1,5
Power supply3х380 V, 50 Hz
Rate of turn, rpm2 900
Type of configurationwith engine
Installation Typehorizontal
Nom.flow rate, m3/h4
Nom.head, m32
Impeller diameter, mm160
Show all features (24)
Documentation
Ukraine: Pre-order only
Poland: Pre-order only
Germany: Pre-order only
Italy: Pre-order only
$1,273 (netto)
Buy in 1 click
Добавить в сравнение
We deliver anywhere in the world
Industrial horizontal centrifugal pumps of the TKHWB series with explosion-proof electric motor Ex. For pumping chemically aggressive liquids, salt solutions, seawater, alkalis, acid solutions, mineral fertilisers UAN, caustic solutions for SIP equipment washing. For distilleries and breweries - for pumping batch, wort, used as a GDFO pump, mash and bards. It is also ideal for pumping fusel oils and alcoholic liquids. Pumps of this series are used for ultrafiltration and nanofiltration plants, permeate and filtrate supply.
Category: Monobloc Stainless Console Pumps
ProducerBTS Engineering
MaterialAISI 304 stainless steel
PumpTypeconsole
Output pipe diameterDN25
Input pipe diameterDN25
Material of flow channelAISI 304 stainless steel
Weight, kg39
Explosion protectionYes
Suction capacity (NPSH), m2,3
Pump capacity, m3/h4
Serial number of the pumpTKHWB
Drive Typeelectric
Feed height, m32
Country of OriginChina
Warranty, months12
Power capacity, kW1,5
Power supply3х380 V, 50 Hz
Rate of turn, rpm2 900
Type of configurationwith engine
Installation Typehorizontal
Nom.flow rate, m3/h4
Nom.head, m32
Impeller diameter, mm160

Download instructions, catalog for TKHWB 25/160-1./52 (4/32), 1,5 kW, AISI 304, 2900, Ex horizontal stainless steel pump
