Producer | BTS Engineering |
PumpType | console |
Material of flow channel | AISI 304 stainless steel |
Max.temperature, C | 100 |
Explosion protection | No |
Pump capacity, cu.m/hour | 160 |
Drive Type | electric |
Feed height, m | 20 |
Power capacity, kW | 18,5 |
Power supply | 3х380 V, 50 Hz |
Rate of turn, rpm | 1 500 |
Nom.pressure, Mpa | 0,2 |
Installation Type | horizontal |
Nom.head, m | 20 |
Impeller material | AISI 304 stainless steel |
Seal material | VITON |
