Borehole pump 4SDF 54/38 S 4,0 kW

Product list

Home
Pumps
Deep Well Pumps
Borehole pump 4SDF 54/38 S 4,0 kW

Click image for a larger view

Code: 920125

(0 review)

Producer	Calpeda
Max. head, m	246
PumpType	borehole
Max.temperature, C	90
Max.flow rate, m3/h	8
Pump capacity, m3/h	8
Serial number of the pump	4SDF
Drive Type	electric
Feed height, m	246
Country of Origin	Italy
Power capacity, kW	4
Power supply	3х380 V, 50 Hz
Diameter of pump	4" (100 mm)

Show all features (13)

Description Borehole pump 4SDF 54/38 S 4,0 kW

Calpeda downhole pumps of the SDF, SD series are designed for lifting water from wells with a diameter of 4" (DN 100 mm). The SDF series pumps are recommended for pumping clean water containing no more than 150 g/m3 of sand, the SD series-no more than 300 g/m3 of sand.

Category: Deep Well Pumps

Features Borehole pump 4SDF 54/38 S 4,0 kW

Producer	Calpeda
Max. head, m	246
PumpType	borehole
Max.temperature, C	90
Max.flow rate, m3/h	8
Pump capacity, m3/h	8
Serial number of the pump	4SDF
Drive Type	electric
Feed height, m	246
Country of Origin	Italy
Power capacity, kW	4
Power supply	3х380 V, 50 Hz
Diameter of pump	4" (100 mm)
