Borehole pump 4SDM 10/12 S 2,2 kW

Product list

Home
Pumps
Deep Well Pumps
Borehole pump 4SDM 10/12 S 2,2 kW

Click image for a larger view

Code: 920127

(0 review)

Producer	Calpeda
Max. head, m	81
PumpType	borehole
Max.temperature, C	90
Max.flow rate, m3/h	21
Pump capacity, cu.m/hour	21
Serial number of the pump	4SDM
Drive Type	electric
Feed height, m	81
Country of Origin	Italy
Power capacity, kW	2,2
Power supply	1х220 V, 50 Hz
Diameter of pump	4" (100 mm)
Application	скважин

Show all features (14)

Description Borehole pump 4SDM 10/12 S 2,2 kW

Calpeda downhole pumps of the SDF, SD series are designed for lifting water from wells with a diameter of 4" (DN 100 mm). The SDF series pumps are recommended for pumping clean water containing no more than 150 g/m3 of sand, the SD series-no more than 300 g/m3 of sand.

Category: Deep Well Pumps

Features Borehole pump 4SDM 10/12 S 2,2 kW

Producer	Calpeda
Max. head, m	81
PumpType	borehole
Max.temperature, C	90
Max.flow rate, m3/h	21
Pump capacity, cu.m/hour	21
Serial number of the pump	4SDM
Drive Type	electric
Feed height, m	81
Country of Origin	Italy
Power capacity, kW	2,2
Power supply	1х220 V, 50 Hz
Diameter of pump	4" (100 mm)
Application	скважин
