| Producer | Deep Well Pump |
| Material | AISI 304 stainless steel |
| Max. head, m | 145 |
| PumpType | borehole |
| Output pipe diameter | 3" |
| Flow rate, l/min | 267 |
| Max.flow rate, m3/h | 16 |
| Pump capacity, m3/h | 16 |
| Serial number of the pump | 6SR |
| Drive Type | electric |
| Feed height, m | 145 |
| Country of Origin | China |
| Power capacity, kW | 5,5 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 850 |
| Housing material | AISI 304 stainless steel |
| Shaft material | AISI 304 stainless steel |
| Impeller material | plastic |
| Cabel length,m | 4×2.0m㎡×2m |
| Diameter of pump | 6" (150 mm) |
| Producer | Deep Well Pump |
| Material | AISI 304 stainless steel |
| Max. head, m | 145 |
| PumpType | borehole |
| Output pipe diameter | 3" |
| Flow rate, l/min | 267 |
| Max.flow rate, m3/h | 16 |
| Pump capacity, m3/h | 16 |
| Serial number of the pump | 6SR |
| Drive Type | electric |
| Feed height, m | 145 |
| Country of Origin | China |
| Power capacity, kW | 5,5 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 850 |
| Housing material | AISI 304 stainless steel |
| Shaft material | AISI 304 stainless steel |
| Impeller material | plastic |
| Cabel length,m | 4×2.0m㎡×2m |
| Diameter of pump | 6" (150 mm) |
Download instructions, catalog for Deep Well Pump 6SR10/10, Outlet: 3 inch, 5,5kW, 380V
