Food diaphragm pump 150 FOODBOXER

Product list

Home
Pumps
Diaphragm Pumps
Food diaphragm pump 150 FOODBOXER

Click image for a larger view

Code: FB150-A-HTAAT--

(0 review)

Producer	DEBEM
Material	AISI 316L
Max. head, m	70
PumpType	membrane pneumatic
Output pipe diameter	1" 1/4
Diaphragm material at air side	HYTREL
Input pipe diameter	1" 1/4
Material of flow channel	AISI 316L
Material of valve seat	INOX
Max.temperature, C	95
Max.air pressure, bar	7
Weight, kg	21
Flow rate, l/min	220
Max.diameter of solid inclusions, mm	5
Max.flow rate, m3/h	13.2
Pump capacity, cu.m/hour	13.2
Availability of spare parts	Yes
Serial number of the pump	FOODBOXER
Drive Type	pneumatic
Feed height, m	70
Diaphragm material at water side	PTFE
Material of ball valves	PTFE
Max.viscosity, cPs	40 000
Model	FOODBOXER FB150
Country of Origin	Italy
Material of O-ring	PTFE
Max.dry suction head, m	6
Pneumatic circuit connection, inch, f	1/2"
Application	ethers, ethylene, alkalis, slip, slag, phosphoric acid, phosphates, formalin, acetic acid, phenol, alcohol, reverse osmosis systems, urea, sulfur, peroxide, oleum, saturated amine, varnish, paints, carbonate, kaolin suspension, ash, clays, viscous liquids, hydrogen, butane, ammonia, nitric acid
Analogue for	AGRAL DDE-030, AGRAL DDE-100, DELLMECO DM, DELLMECO DMCX, DEPA DB, DEPA L, Debem SANIBOXER, AquaViva, DUOTEK FOOD, AGRAL DDE-600, AlphaDynamic Ruby, AQUA, Astralpool, Debem BOXER, Debem Foodboxer, Duotek AF Zone 2 Atex, PRODOSE, YAMADA NDP, WILDEN, Sera, Seko, ProMinent, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky , FWT, Emec, DEPA M, DOSITEC, DEPA РМ (Р), DUOTEK SANI, AGRAL DDE-60, AGRAL DDE-160, AGRAL DDE-300

Show all features (30)

Description Food diaphragm pump 150 FOODBOXER

Food hygiene pumps FOODBOXER for the food, cosmetic industries. Features pump 150 FOODBOXER - pump capacity up to 220 l / min; - Samozakachivanie liquid to 5 m; - Work in unconfined mode; - Supply air without lubrication; - Rapid regulation while maintaining a high pressure; - The possibility of establishing a suspension; - Adjustable blowing and head; - pipe bends Mnogopatrubnye - Can run dry without any problems; - No electrical connections; - Easily replaceable parts; - Easy-care; - STANDARD: II 3/3 GD c IIB T135 ° C (zone 2) - CONDUCT: II 2/2 GD c IIB T135 ° C (zone 1)
