Pneumatic diaphragm pump BOXER 90 ALU IB90-ALHTAAT--

Pneumatic diaphragm pump BOXER 90 ALU IB90-ALHTAAT--

Click image for a larger view

Code: IB90-ALHTAAT--

(0 review)

Producer	DEBEM
Material	AL
PumpType	membrane pneumatic
Diaphragm material at air side	HYTREL
Material of flow channel	AL
Material of valve seat	AISI 316 stainless steel
Flow rate, l/min	100
Max.flow rate, m3/h	6
Pump capacity, m3/h	6
Availability of spare parts	Yes
Serial number of the pump	BOXER
Drive Type	pneumatic
Diaphragm material at water side	PTFE
Material of ball valves	AISI 316 stainless steel
Model	BOXER 90
Country of Origin	Italy
Material of O-ring	PTFE
Application	ethers, ethylene, alkalis, slip, slag, phosphoric acid, phosphates, formalin, acetic acid, phenol, alcohol, reverse osmosis systems, urea, sulfur, peroxide, oleum, saturated amine, varnish, paints, carbonate, kaolin suspension, ash, clays, viscous liquids, hydrogen, butane, ammonia, nitric acid
Analogue for	AGRAL DDE-030, AGRAL DDE-100, DELLMECO DM, DELLMECO DMCX, DEPA DB, DEPA L, Debem SANIBOXER, AquaViva, DUOTEK FOOD, AGRAL DDE-600, AlphaDynamic Ruby, AQUA, Astralpool, Debem BOXER, Debem Foodboxer, Duotek AF Zone 2 Atex, PRODOSE, YAMADA NDP, WILDEN, Sera, Seko, ProMinent, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky , FWT, Emec, DEPA M, DOSITEC, DEPA РМ (Р), DUOTEK SANI, AGRAL DDE-60, AGRAL DDE-160, AGRAL DDE-300

Show all features (19)

Documentation

Description Pneumatic diaphragm pump BOXER 90 ALU IB90-ALHTAAT--

The diaphragm air pump BOXER 90 for viscous liquids Productivity - up to 100 l / min Connection - 1 " Versions: PP - PVDF - ALU - AISI 316 Main features of the diaphragm pump 81 BOXER - Performance up to 100 l / min - Self-priming liquid to 4 m - Work in unconfined mode - pumping liquids containing solid particles and insoluble - Pumping of highly viscous liquids - Support in the "dry run" - Perform barrel pump functions - Perhaps the body design for total immersion in the pumped liquid - Easy maintenance and parts replacement - STANDARD: II 3/3 GD c IIB T135 ° C (zone 2) - CONDUCT: II 2/2 GD c IIB T135 ° C (zone 1)

Category: Diaphragm Pumps

Features Pneumatic diaphragm pump BOXER 90 ALU IB90-ALHTAAT--

Producer	DEBEM
Material	AL
PumpType	membrane pneumatic
Diaphragm material at air side	HYTREL
Material of flow channel	AL
Material of valve seat	AISI 316 stainless steel
Flow rate, l/min	100
Max.flow rate, m3/h	6
Pump capacity, m3/h	6
Availability of spare parts	Yes
Serial number of the pump	BOXER
Drive Type	pneumatic
Diaphragm material at water side	PTFE
Material of ball valves	AISI 316 stainless steel
Model	BOXER 90
Country of Origin	Italy
Material of O-ring	PTFE
Application	ethers, ethylene, alkalis, slip, slag, phosphoric acid, phosphates, formalin, acetic acid, phenol, alcohol, reverse osmosis systems, urea, sulfur, peroxide, oleum, saturated amine, varnish, paints, carbonate, kaolin suspension, ash, clays, viscous liquids, hydrogen, butane, ammonia, nitric acid
Analogue for	AGRAL DDE-030, AGRAL DDE-100, DELLMECO DM, DELLMECO DMCX, DEPA DB, DEPA L, Debem SANIBOXER, AquaViva, DUOTEK FOOD, AGRAL DDE-600, AlphaDynamic Ruby, AQUA, Astralpool, Debem BOXER, Debem Foodboxer, Duotek AF Zone 2 Atex, PRODOSE, YAMADA NDP, WILDEN, Sera, Seko, ProMinent, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, Graco Husky , FWT, Emec, DEPA M, DOSITEC, DEPA РМ (Р), DUOTEK SANI, AGRAL DDE-60, AGRAL DDE-160, AGRAL DDE-300
