• Microprocessor control.
• informative LCD display with backlight
• Measurement ranges:
0-14 pH;
-1000 +1400 mV Rx;
chlorine: 0-2 mg/l, 0-20 mg/l, 0-200 mg/l;
ppm: 0-2 ppm, 0-20 ppm, 0-200 ppm;
0-100°С.
• Setting 2 independent setpoint points on the measured parameter
• Control dosing modes: constant ON/OFF with hysteresis installation or PROP proportional.
• Choice of direction of dosing mode: direct or reverse
• Setting the start delay time for metering pumps
• 2 independent proportional ON / OFF outputs (proximity relay) with PWM mode
• Support for PT100 temperature sensor.
• Manual (25 ° C) or automatic temperature compensation (when connecting a PT100 temperature sensor)
• Alarm MAX. reagent concentration (optional)
• Alarm MIN. reagent concentration (optional)
• Alarm for continuous dosing time and failure to reach the Set Point (optional)
• ON / OFF output (proximity relay) for alarm (optional)
• Output 4-20 mA (optional)
• Galvanically isolated outputs
