AG-S/CONTROL TURBIDITY liquid analyzer for turbidity monitoring and determination.
AG-S/Control TURBIDITY Turbidity Controller -a series of liquid analyzers is based on microprocessor technology and provides a high degree of reliability for turbidity control.
• Graphic display with backlight,
• 2 outputs ON-OFF (contactless relay),
• 2 independent galvanically isolated outputs 4-20 mA,
• Alarm,
• ON / OFF output (contactless relay) for alarm,
• ON-OFF output (contactless relay) for connecting actuators, for example, for cleaning the sensor,
• Support for flow and reagent level sensors.
* Measurement range: 0-1000 NTU.
• Universal input voltage 100-240V AC 50 Hz.
• Class of dust and moisture protection: IP65.
• Wall mount.
• Dimensions: 202x201x135 mm
