GM25/1.0, PVC, 380V diaphragm motor dosing pump

Product list

Home
Pumps
Dosing Equipment, Diaphragm, Plunger, Peristaltic Pumps
Motorised Diaphragm Dosing Pumps
GM25/1.0, PVC, 380V diaphragm motor dosing pump

GM25/1.0, PVC, 380V diaphragm motor dosing pump

Click image for a larger view

Code: 1025069

(0 review)

Producer	BTS Engineering
Material	PVC
PumpType	membrane motor
Explosion protection	No
Pump capacity, m3/h	0.025
Serial number of the pump	GM
Drive Type	electric
Country of Origin	China
Power capacity, kW	0,37
Power supply	3х380 V, 50 Hz
Operating temperature	-5°C + 50°C
Flow rate, l/h	25
Pressure, bar	10
Diaphragm stroke per min.	48
Connection	6x9mm PE Hose
Diaphragm diameter, mm	65

Show all features (16)

Documentation

Description GM25/1.0, PVC, 380V diaphragm motor dosing pump

The GB series diaphragm metering pumps are robust and reliable motor-driven diaphragm metering pumps. The diaphragm is a five-layer PTFE composite diaphragm with a reinforced back plate. It is a reliable pump with a long service life. Both the stroke length and stroke speed can be adjusted to change the pump performance. It is an ideal pump for pumping and injecting chemicals in water treatment systems.

Category: Motorised Diaphragm Dosing Pumps

Features GM25/1.0, PVC, 380V diaphragm motor dosing pump

Producer	BTS Engineering
Material	PVC
PumpType	membrane motor
Explosion protection	No
Pump capacity, m3/h	0.025
Serial number of the pump	GM
Drive Type	electric
Country of Origin	China
Power capacity, kW	0,37
Power supply	3х380 V, 50 Hz
Operating temperature	-5°C + 50°C
Flow rate, l/h	25
Pressure, bar	10
Diaphragm stroke per min.	48
Connection	6x9mm PE Hose
Diaphragm diameter, mm	65
