AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V
Click image for a larger view
AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V
AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V
AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V
AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V
AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V
More +1

AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V

Code: MSB0133BB00200
(0 review)
ProducerAQUA
MaterialPP
PumpTypemembrane motor
Material of valve seatPVC
Explosion protectionNo
Pump capacity, cu.m/hour0.133
Serial number of the pumpMS
Drive Typeelectric
Material of ball valvesPYREX
Country of OriginItaly
Power capacity, kW0,37
Power supply3х380 V, 50 Hz
ProtectionIP55
Material of O-ringVITON
Flow rate, l/h133
Pressure, bar10
Diaphragm stroke per min.126
Connection3/8"BspF
Meterial of head pumpPP
Diameter of ball valves, mm8,5
Material of the ball cage guidePP
Material of the connectionPVC
Diaphragm stroke length, mm4
Diaphragm diameter, mm110
Diaphragm materialPTFE
Analogue forOBL, AQUA, Astralpool, PRODOSE, WILDEN, Sera, Seko, ProMinent, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, FWT, Emec, DOSITEC
Show all features (26)
Documentation
Ukraine: Pre-order only
Poland: Pre-order only
Germany: Pre-order only
Italy: Pre-order only
$1,307.63 (netto)
Добавить в сравнение
We deliver anywhere in the world
Diaphragm motor pumps for dosing liquids from the Italian company AQUA, MS series, are used in the food industry, beverage production, water treatment, wastewater treatment, pulp and paper industry, irrigation and drainage. The pumps are manufactured to high quality standards, are easy to use and require minimal maintenance. The pumped liquid is separated from the drive by a diaphragm. Thus, it is protected from the harmful effects of the liquid. Accuracy +/- 2% from 10% to 100% of the nominal flow. Standard micrometric manual adjustment, 1 mm per revolution. Flow rate adjustment 0-100%.
Category: Motorised Diaphragm Dosing Pumps
ProducerAQUA
MaterialPP
PumpTypemembrane motor
Material of valve seatPVC
Explosion protectionNo
Pump capacity, cu.m/hour0.133
Serial number of the pumpMS
Drive Typeelectric
Material of ball valvesPYREX
Country of OriginItaly
Power capacity, kW0,37
Power supply3х380 V, 50 Hz
ProtectionIP55
Material of O-ringVITON
Flow rate, l/h133
Pressure, bar10
Diaphragm stroke per min.126
Connection3/8"BspF
Meterial of head pumpPP
Diameter of ball valves, mm8,5
Material of the ball cage guidePP
Material of the connectionPVC
Diaphragm stroke length, mm4
Diaphragm diameter, mm110
Diaphragm materialPTFE
Analogue forOBL, AQUA, Astralpool, PRODOSE, WILDEN, Sera, Seko, ProMinent, Milwaukee, MILTON ROY, Jesco Pump, Injecta, Grundfos, FWT, Emec, DOSITEC

Download instructions, catalog for AQUA MSB detergent dosing driven motor diaphragm pump, PP, 133 l/h, 10 bar, 0.37 kW, 380V
