| Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| PumpType | in-line |
| Output pipe diameter | DN125 |
| Input pipe diameter | DN125 |
| Material of flow channel | AISI 304 stainless steel |
| Max.temperature, C | 120 |
| Weight, kg | 180 |
| Explosion protection | Yes |
| Pump capacity, m3/h | 160 |
| Serial number of the pump | BGLHB |
| Drive Type | electric |
| Feed height, m | 12.5 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 11 |
| Dimensions, mm | 520x430x830 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 880 |
| Protection | IP55 |
| Seal | Mechanical Seal, Carbon-SiC-NBR |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 160 |
| Nom.head, m | 12.5 |

    | Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| PumpType | in-line |
| Output pipe diameter | DN125 |
| Input pipe diameter | DN125 |
| Material of flow channel | AISI 304 stainless steel |
| Max.temperature, C | 120 |
| Weight, kg | 180 |
| Explosion protection | Yes |
| Pump capacity, m3/h | 160 |
| Serial number of the pump | BGLHB |
| Drive Type | electric |
| Feed height, m | 12.5 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 11 |
| Dimensions, mm | 520x430x830 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 880 |
| Protection | IP55 |
| Seal | Mechanical Seal, Carbon-SiC-NBR |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 160 |
| Nom.head, m | 12.5 |
Download instructions, catalog for IHG BGLHB 125-100 (160/12,5), 11kW, 2880, Ex Stainless Steel Vertical Pump
