| Producer | BTS Engineering |
| Material | cast iron |
| Max. head, m | 17 |
| PumpType | in-line |
| Output pipe diameter | DN50 |
| Input pipe diameter | DN50 |
| Material of flow channel | cast iron |
| Max.temperature, C | 120 |
| Weight, kg | 35 |
| Max.flow rate, m3/h | 30 |
| Pump capacity, cu.m/hour | 30 |
| Availability of spare parts | yes |
| Serial number of the pump | JL |
| Drive Type | electric |
| Feed height, m | 17 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 1,5 |
| Power supply | 1х220 V, 50 Hz |
| Nom.pressure, Mpa | 1,6 |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 24 |
| Nom.head, m | 14 |
| Net weight,kg | 29 |
| Application | горячего водоснабжения, теплоносителя, гвс, гликоля, системы кондиционирования, подачи воды, этиленгликоля, горячей воды, котла, водоснабжения, сушильной камеры, cooling, полива, градирни, ледяной воды, оборотного водоснабжения, отопления, сушки, циркуляции, повышения давления, water |
| Analogue for | DAB CM, WILO TOP-S, DAB CM-G, DAB DCM, DAB DCM-G, DAB CP, DAB CP-G, DAB DCP, DAB ALP, DAB KLM, DAB KLP, DAB DKLM, DAB DKLP, DAB ALM, WILO VeroLine-IPL, Calpeda NM, WILO CronoLine-IL-E, DAB DCP-G, EBARA LPS, EBARA EGO EASY, SPRUT 1V, Speroni SCR, KSB Etaline, PSPRUT 3VP, KSB Calio, Grundfos UPS, SPRUT 3VP, SPRUT GPD, CALPEDA NR, CALPEDA NC, KSB Etaline-R, KSB Etanorm, KSB Calio S |
| Producer | BTS Engineering |
| Material | cast iron |
| Max. head, m | 17 |
| PumpType | in-line |
| Output pipe diameter | DN50 |
| Input pipe diameter | DN50 |
| Material of flow channel | cast iron |
| Max.temperature, C | 120 |
| Weight, kg | 35 |
| Max.flow rate, m3/h | 30 |
| Pump capacity, cu.m/hour | 30 |
| Availability of spare parts | yes |
| Serial number of the pump | JL |
| Drive Type | electric |
| Feed height, m | 17 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 1,5 |
| Power supply | 1х220 V, 50 Hz |
| Nom.pressure, Mpa | 1,6 |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 24 |
| Nom.head, m | 14 |
| Net weight,kg | 29 |
| Application | горячего водоснабжения, теплоносителя, гвс, гликоля, системы кондиционирования, подачи воды, этиленгликоля, горячей воды, котла, водоснабжения, сушильной камеры, cooling, полива, градирни, ледяной воды, оборотного водоснабжения, отопления, сушки, циркуляции, повышения давления, water |
| Analogue for | DAB CM, WILO TOP-S, DAB CM-G, DAB DCM, DAB DCM-G, DAB CP, DAB CP-G, DAB DCP, DAB ALP, DAB KLM, DAB KLP, DAB DKLM, DAB DKLP, DAB ALM, WILO VeroLine-IPL, Calpeda NM, WILO CronoLine-IL-E, DAB DCP-G, EBARA LPS, EBARA EGO EASY, SPRUT 1V, Speroni SCR, KSB Etaline, PSPRUT 3VP, KSB Calio, Grundfos UPS, SPRUT 3VP, SPRUT GPD, CALPEDA NR, CALPEDA NC, KSB Etaline-R, KSB Etanorm, KSB Calio S |
Download instructions, catalog for JL 50 Centrifugal pump
