| Producer | BTS Engineering |
| Material | cast iron |
| PumpType | in-line |
| Output pipe diameter | DN65 |
| Input pipe diameter | DN65 |
| Material of flow channel | cast iron |
| Weight, kg | 107 |
| Explosion protection | No |
| Suction capacity (NPSH), m | 2,5 |
| Pump capacity, m3/h | 23.4 |
| Serial number of the pump | TKG |
| Drive Type | electric |
| Feed height, m | 44 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 5,5 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 23.4 |
| Nom.head, m | 44 |
| Impeller diameter, mm | 185 |

    | Producer | BTS Engineering |
| Material | cast iron |
| PumpType | in-line |
| Output pipe diameter | DN65 |
| Input pipe diameter | DN65 |
| Material of flow channel | cast iron |
| Weight, kg | 107 |
| Explosion protection | No |
| Suction capacity (NPSH), m | 2,5 |
| Pump capacity, m3/h | 23.4 |
| Serial number of the pump | TKG |
| Drive Type | electric |
| Feed height, m | 44 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 5,5 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 23.4 |
| Nom.head, m | 44 |
| Impeller diameter, mm | 185 |
Download instructions, catalog for Pump for drying IRG TKG 65/185-5.5/2 (23.4/44), 5.5 kW, 2900
