| Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| Max. head, m | 48 |
| PumpType | multi-stage |
| Output pipe diameter | DN25 |
| Input pipe diameter | DN25 |
| Material of flow channel | AISI 304 stainless steel |
| Max.temperature, C | 120 |
| Max.flow rate, m3/h | 2 |
| Explosion protection | Yes |
| Pump capacity, m3/h | 2 |
| Serial number of the pump | BVS |
| Drive Type | electric |
| Feed height, m | 48 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 0,55 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Housing material | AISI 304 stainless steel |
| Seal | Mechanical Seal |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 1 |
| Nom.head, m | 45 |
| Impeller material | AISI 304 stainless steel |
| Analogue for | Grundfos CR, Speroni RVM, Ebara EVMS, EBARA EVMW, EBARA EVM, Varna, VMtec PRIMA VMEV, Lowara SV, Aquatica LVR, Dab KVC, Calpeda MXV |
| Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| Max. head, m | 48 |
| PumpType | multi-stage |
| Output pipe diameter | DN25 |
| Input pipe diameter | DN25 |
| Material of flow channel | AISI 304 stainless steel |
| Max.temperature, C | 120 |
| Max.flow rate, m3/h | 2 |
| Explosion protection | Yes |
| Pump capacity, m3/h | 2 |
| Serial number of the pump | BVS |
| Drive Type | electric |
| Feed height, m | 48 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 0,55 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Housing material | AISI 304 stainless steel |
| Seal | Mechanical Seal |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 1 |
| Nom.head, m | 45 |
| Impeller material | AISI 304 stainless steel |
| Analogue for | Grundfos CR, Speroni RVM, Ebara EVMS, EBARA EVMW, EBARA EVM, Varna, VMtec PRIMA VMEV, Lowara SV, Aquatica LVR, Dab KVC, Calpeda MXV |
Download instructions, catalog for Pump for alcohol explosion-proof BVS 1-8, 0.55 kW, AISI 304, Ex
