| Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| Max. head, m | 90 |
| PumpType | multi-stage |
| Output pipe diameter | DN40 |
| Input pipe diameter | DN40 |
| Material of flow channel | AISI 304 stainless steel |
| Max.temperature, C | 120 |
| Weight, kg | 66 |
| Max.flow rate, m3/h | 13 |
| Explosion protection | No |
| Pump capacity, m3/h | 13 |
| Serial number of the pump | BVS |
| Drive Type | electric |
| Feed height, m | 90 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 3 |
| Length of transport packing, cm | 33 |
| Width of transport packing, cm | 31 |
| Height of transport packing, cm | 94 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Housing material | AISI 304 stainless steel |
| Seal | Mechanical Seal |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 10 |
| Nom.head, m | 72 |
| Impeller material | AISI 304 stainless steel |
| Transport packing volume, cbm | 0,096 |
| Analogue for | EBARA EVMW, Dab KVC, Aquatica LVR, Lowara SV, VMtec PRIMA VMEV, Varna, EBARA EVM, Ebara EVMS, Speroni RVM, Grundfos CR, Calpeda MXV |
| Producer | BTS Engineering |
| Material | AISI 304 stainless steel |
| Max. head, m | 90 |
| PumpType | multi-stage |
| Output pipe diameter | DN40 |
| Input pipe diameter | DN40 |
| Material of flow channel | AISI 304 stainless steel |
| Max.temperature, C | 120 |
| Weight, kg | 66 |
| Max.flow rate, m3/h | 13 |
| Explosion protection | No |
| Pump capacity, m3/h | 13 |
| Serial number of the pump | BVS |
| Drive Type | electric |
| Feed height, m | 90 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 3 |
| Length of transport packing, cm | 33 |
| Width of transport packing, cm | 31 |
| Height of transport packing, cm | 94 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Housing material | AISI 304 stainless steel |
| Seal | Mechanical Seal |
| Type of configuration | with engine |
| Installation Type | vertical |
| Nom.flow rate, m3/h | 10 |
| Nom.head, m | 72 |
| Impeller material | AISI 304 stainless steel |
| Transport packing volume, cbm | 0,096 |
| Analogue for | EBARA EVMW, Dab KVC, Aquatica LVR, Lowara SV, VMtec PRIMA VMEV, Varna, EBARA EVM, Ebara EVMS, Speroni RVM, Grundfos CR, Calpeda MXV |
Download instructions, catalog for BVS 10-9, 3 kW, AISI 304 multistage pump
