Speroni RSXМ 4-5 stainless multistage horizontal pump

Product list

Home
Pumps
Multistage Pumps
Speroni RSXМ 4-5 stainless multistage horizontal pump

Speroni RSXМ 4-5 stainless multistage horizontal pump

Click image for a larger view

Code: 102207600

Producer	Speroni
Material	AISI 304 stainless steel
Max. head, m	48
Output pipe diameter	G 1"
Input pipe diameter	G 1 1/4"
Material of flow channel	AISI 304 stainless steel
Max.temperature, C	100
Weight, kg	11
Flow rate, l/min	9.6
Max.flow rate, m3/h	9.6
Serial number of the pump	RSX
Feed height, m	48
Country of Origin	Italy
Power capacity, kW	0,75
Power supply	1х220 V, 50 Hz
Rate of turn, rpm	2 850
Protection	IP55
Type of configuration	with engine

Show all features (18)

Description Speroni RSXМ 4-5 stainless multistage horizontal pump

Horizontal multistage stainless steel pumps of the Speroni RSX/RSXM series have a design in which several impellers sequentially mounted one after another in a stainless steel casing, increase pressure from stage to stage. Pumps have good hydraulic characteristics and high capacity. Liquid temperature is to 35°С. It is appointed for the durable operation.

Category: Multistage Pumps

Features Speroni RSXМ 4-5 stainless multistage horizontal pump

Producer	Speroni
Material	AISI 304 stainless steel
Max. head, m	48
Output pipe diameter	G 1"
Input pipe diameter	G 1 1/4"
Material of flow channel	AISI 304 stainless steel
Max.temperature, C	100
Weight, kg	11
Flow rate, l/min	9.6
Max.flow rate, m3/h	9.6
Serial number of the pump	RSX
Feed height, m	48
Country of Origin	Italy
Power capacity, kW	0,75
Power supply	1х220 V, 50 Hz
Rate of turn, rpm	2 850
Protection	IP55
Type of configuration	with engine
