| Producer | BTS Engineering |
| Material | AISI 316 stainless steel |
| Max. head, m | 124 |
| PumpType | multi-stage |
| Output pipe diameter | DN32 |
| Input pipe diameter | DN32 |
| Material of flow channel | AISI 316 stainless steel |
| Max.temperature, C | 120 |
| Max.flow rate, m3/h | 8 |
| Explosion protection | No |
| Pump capacity, m3/h | 8 |
| Availability of spare parts | Yes |
| Serial number of the pump | CDLF |
| Drive Type | electric |
| Feed height, m | 124 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 3 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Housing material | AISI 316 stainless steel |
| Installation Type | vertical |
| Analogue for | Speroni RVM, Ebara EVMS, EBARA EVMW, EBARA EVM, Varna, VMtec PRIMA VMEV, Lowara SV, Aquatica LVR, Dab KVC, Calpeda MXV, Grundfos CR |
| Producer | BTS Engineering |
| Material | AISI 316 stainless steel |
| Max. head, m | 124 |
| PumpType | multi-stage |
| Output pipe diameter | DN32 |
| Input pipe diameter | DN32 |
| Material of flow channel | AISI 316 stainless steel |
| Max.temperature, C | 120 |
| Max.flow rate, m3/h | 8 |
| Explosion protection | No |
| Pump capacity, m3/h | 8 |
| Availability of spare parts | Yes |
| Serial number of the pump | CDLF |
| Drive Type | electric |
| Feed height, m | 124 |
| Country of Origin | China |
| Warranty, months | 12 |
| Power capacity, kW | 3 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 900 |
| Protection | IP55 |
| Housing material | AISI 316 stainless steel |
| Installation Type | vertical |
| Analogue for | Speroni RVM, Ebara EVMS, EBARA EVMW, EBARA EVM, Varna, VMtec PRIMA VMEV, Lowara SV, Aquatica LVR, Dab KVC, Calpeda MXV, Grundfos CR |
Download instructions, catalog for Multistage pump CDLF 4-130, AISI 316
