| Producer | ALUNAK |
| Material | AISI 304 stainless steel |
| Max. head, m | 60 |
| PumpType | vortex |
| Output pipe diameter | DN 20 |
| Input pipe diameter | DN 20 |
| Max.temperature, C | 200 |
| Weight, kg | 11 |
| Flow rate, l/min | 60 |
| Max.flow rate, m3/h | 3.6 |
| Explosion protection | No |
| Pump capacity, cu.m/hour | 3.6 |
| Serial number of the pump | WD |
| Drive Type | electric |
| Feed height, m | 60 |
| Country of Origin | China |
| Temperature (min), °C | -30 |
| Power capacity, kW | 0,75 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 760 |
| Operating temperature | thermal conductivity water +5˚С~+160˚С; thermal conductivity oil +5˚С~+200˚С; glycol/silicone oil -30˚С~+180˚С |
| Installation Type | horizontal |
| Nom.head, m | 40 |
| Pressure, bar | 10 |
| Producer | ALUNAK |
| Material | AISI 304 stainless steel |
| Max. head, m | 60 |
| PumpType | vortex |
| Output pipe diameter | DN 20 |
| Input pipe diameter | DN 20 |
| Max.temperature, C | 200 |
| Weight, kg | 11 |
| Flow rate, l/min | 60 |
| Max.flow rate, m3/h | 3.6 |
| Explosion protection | No |
| Pump capacity, cu.m/hour | 3.6 |
| Serial number of the pump | WD |
| Drive Type | electric |
| Feed height, m | 60 |
| Country of Origin | China |
| Temperature (min), °C | -30 |
| Power capacity, kW | 0,75 |
| Power supply | 3х380 V, 50 Hz |
| Rate of turn, rpm | 2 760 |
| Operating temperature | thermal conductivity water +5˚С~+160˚С; thermal conductivity oil +5˚С~+200˚С; glycol/silicone oil -30˚С~+180˚С |
| Installation Type | horizontal |
| Nom.head, m | 40 |
| Pressure, bar | 10 |
Download instructions, catalog for High temperature vortex pump WD-10E, 380V made of stainless steel -30°C+200°C
