| Producer | Modo |
| Material | cast iron |
| Max. head, m | 28 |
| PumpType | console |
| Output pipe diameter | DN150 |
| Input pipe diameter | DN150 |
| Max.flow rate, m3/h | 340 |
| Pump capacity, m3/h | 340 |
| Serial number of the pump | P-6 |
| Drive Type | internal combustion engine |
| Feed height, m | 28 |
| Country of Origin | China |
| Power capacity, kW | 41 |
| Rate of turn, rpm | 1 500 |
| Type | diesel |
| Seal | Mechanical Seal |
| Shaft material | AISI 420 |
| Installation Type | horizontal |
| Impeller material | NODULAR CAST IRON |
| Specific fuel consumption in g/kWh | 251 |
| Producer | Modo |
| Material | cast iron |
| Max. head, m | 28 |
| PumpType | console |
| Output pipe diameter | DN150 |
| Input pipe diameter | DN150 |
| Max.flow rate, m3/h | 340 |
| Pump capacity, m3/h | 340 |
| Serial number of the pump | P-6 |
| Drive Type | internal combustion engine |
| Feed height, m | 28 |
| Country of Origin | China |
| Power capacity, kW | 41 |
| Rate of turn, rpm | 1 500 |
| Type | diesel |
| Seal | Mechanical Seal |
| Shaft material | AISI 420 |
| Installation Type | horizontal |
| Impeller material | NODULAR CAST IRON |
| Specific fuel consumption in g/kWh | 251 |
Download instructions, catalog for P-6 self-priming diesel pumping station (motor pump)
