Diesel pumping station SPDW150 300 m3/h, 35 m, with Cummins engine, 67 kW, 1800 rpm

Product list

Home
Pumps
Water Supply and Fire Fighting Stations, Motor Pumps
Diesel pumping station SPDW150 300 m3/h, 35 m, with Cummins engine, 67 kW, 1800 rpm

Diesel pumping station SPDW150 300 m3/h, 35 m, with Cummins engine, 67 kW, 1800 rpm

Click image for a larger view

Code: 1051627

(0 review)

Producer	BTS Engineering
Max. head, m	35
PumpType	console
Output pipe diameter	150 mm
Input pipe diameter	150 mm
Drive Type	internal combustion engine
Feed height, m	35
Country of Origin	China
Rate of turn, rpm	1 800
Housing material	cast iron GG 25
Seal	Mechanical Seal
Shaft material	AISI 420
Impeller material	AISI 304 stainless steel

Show all features (13)

Documentation

Description Diesel pumping station SPDW150 300 m3/h, 35 m, with Cummins engine, 67 kW, 1800 rpm

Diesel pumping station with pump model SPDW150, capacity 300 m3/h, head 30-35 m, Filling system: RV60, Max. suction: 9.5 m, Cummins engine: 4BTA3.9-P90, 67 kW, 1800 rpm, 4 cylinders. Control panel, fuel tank with 8-hour running time. Scope of delivery: Pump + Engine + Control panel + Fuel tank + Battery + Trailer, without canopy and brake.

Category: Water Supply and Fire Fighting Stations, Motor Pumps

Features Diesel pumping station SPDW150 300 m3/h, 35 m, with Cummins engine, 67 kW, 1800 rpm

Producer	BTS Engineering
Max. head, m	35
PumpType	console
Output pipe diameter	150 mm
Input pipe diameter	150 mm
Drive Type	internal combustion engine
Feed height, m	35
Country of Origin	China
Rate of turn, rpm	1 800
Housing material	cast iron GG 25
Seal	Mechanical Seal
Shaft material	AISI 420
Impeller material	AISI 304 stainless steel
